Open source modern lathe
The purpose of this project is to waste your money by another way
The purpose of this project is to a affordful desktop lathe, can work well with aluminium, also work with steel.
A means work well with good surface.
B means can work, but normal surface.
| Material | Work Rate | |
|---|---|---|
| Plastics | A+ | |
| Wood | A+ | |
| Aluminium | A++ | |
| Copper | A++ | |
| Normal Steel | B | |
| Titanium | A |
-
Desktop, around 740x340x700mm
-
750W Spindle Servo Motor
-
Maximum workpiece diameter: less than140mm
-
Maximum workpiece length: around 200mm
-
No tailstock (at least not now)
-
Enclosed
-
Optional liquid cooling
-
Less than $1000 total
-
Acceptable accuracy (0.01-0.02mm)
-
Linuxcnc + Ethercat by default
